Switching current: 10mA - 10A
Nominal coil power: 600mW
Test voltage (rms): 5000V
Switching current: 5mA - 12A
Nominal coil power: 750mW
Test voltage (rms): 5000V
The following product variants are available:
Other relay coil variants on request.
Maximum one packing unit available, contains 15 pieces.
| Number of Contacts NO: | 3 |
| Number of Contacts NC: | 1 |
| Contact Material: | AgSnO2 |
| Contact Type (Output Contacts): | Crown Contacts |
| Nominal Coil Power: | 0.75 W |
| Switching Current Range: | 5 mA to 6 A (control contacts) / 10 mA to 12 A (output contacts) |
| Test Voltage open Contact (rms): | 1500 V |
| Test Voltage between Contacts (rms): | 2500 V, 5000 V, 4000 V ** |
| Test Voltage Coil/Contact (rms): | 2500 V |
| Length in mm: | 46.4 |
| Width in mm: | 16 |
| Height in mm: | 30.7 |
| Type of Protection: | RT II |
| Approvals: | UL, cUL, TÜV |
| Options, Accessories: | Print socket SRP-SIR4 |
| Areas of Application: | door controls, motion control, transportation, farm machinery |
